Specification
Product Type | CERAMIC YARN INSULATED THERMOCOPLE WIRE |
Brand | ELTEC |
Thermocouple Type | K, N & E |
Insulation Material | CERAMIC YARN |
Temperature | Up to 1000 C |
Length | 100 Mtrs. / 500 Mtrs. / 1000 Mtrs. / 2000 Mtrs. |
Accuracy | Class 1 |
Thermocouple Grade Wire | THERMOCOUPLE ORIGINAL GRADE |
Number Of Core | 2 |
Usage/Application | Used as a temperature sensor to measure temperature in furnace |
Limit Of Error | +-1.1 or 0.4% whichever is greater |
Outer Jacket | CERAMIC FIBER |
Referred Standards | ANSI MC 96.1 & ASTM E 230 |
Outer Braiding | SS WIRE optional |
Size | 20 AWG to 12 AWG solid wire |
Temperature Withstanding Capacity | 1000 C |
